The Bottle Chimney
Brymbo, Wrexham, Wales
A Grade II listed building in Mount Zion, Brymbo, Wrexham, designated on 1 December 1995.
The record
- Designation
- Listed building, Grade II
- Broad class
- Industrial
- Date of designation
- 1 December 1995
- Locality
- Mount Zion
- Community
- Brymbo
- Unitary authority
- Wrexham
- Country
- Wales
- Coordinates
- 53.07695, -3.06882
- Cadw reference
- 13484
Slide toward Today to fade the historical sheet and see the modern map underneath.
David Rumsey Map Collection, Stanford LibrariesDavid Rumsey Map Collection, Stanford LibrariesDavid Rumsey Map Collection, Stanford LibrariesLlyfrgell Genedlaethol Cymru – The National Library of WalesDavid Rumsey Map Collection, Stanford Libraries
5 historical maps cover this location, the earliest the 1608 map "(13) Cambriae Typus." (David Rumsey Map Collection, Stanford Libraries).
Historical maps covering this location
- 1608 · (13) Cambriae Typus. (David Rumsey Map Collection, Stanford Libraries)
- 1795 · To Sir Watkin Williams-Wynn Bart ... the map of the six counties of North Wales is most… (Llyfrgell Genedlaethol Cymru – The National Library of Wales)
- 1883 · Watershed map England, Wales 3. (David Rumsey Map Collection, Stanford Libraries)
- 1898 · 121 Wrexham (Hills) (David Rumsey Map Collection, Stanford Libraries)
- 1901 · Sheet 9 and 10. (David Rumsey Map Collection, Stanford Libraries)
Cadw's description
Location
Occupies an elevated site to the E of the Brymbo Lead Smelting Works site, between the reservoir and the Minera Road.
History
Brymbo Lead Smelting Works was established c1792, by John Wilkinson. It continued in use until the 1880s and with little significant change it was then used for a time to manufacture carbon. The bottle chimney ('Brymbo Bottle') was part of the system for collecting lead sublimate in the smelting process: use of a bottle chimney in this way appears to have been distinctive to Wilkinson, and this is the only one to survive. Originally c30m high, it was partially demolished in 1962.
Exterior
A tapering circular structure now with a height of c6m. Roughly coursed rubble, with 2 openings in the base, with cast-iron lintels.
Reason for designation
Significant as the only standing structure associated with Wilkinson's Brymbo Lead Smelting Works to survive. An extremely rare building type, and the only one of its particular type to survive in Wales.
