Drawbridge on S side of Victoria Dock
Caernarfon, Gwynedd, Wales
A Grade II listed building in Victoria Dock, Caernarfon, Gwynedd, designated on 3 May 2002.
The record
- Designation
- Listed building, Grade II
- Broad class
- Maritime
- Date of designation
- 3 May 2002
- Locality
- Victoria Dock
- Town
- Caernarfon
- Community
- Caernarfon
- Unitary authority
- Gwynedd
- Country
- Wales
- Coordinates
- 53.14293, -4.27616
- Cadw reference
- 26611
Slide toward Today to fade the historical sheet and see the modern map underneath.
David Rumsey Map Collection, Stanford LibrariesDavid Rumsey Map Collection, Stanford LibrariesDavid Rumsey Map Collection, Stanford LibrariesDavid Rumsey Map Collection, Stanford LibrariesDavid Rumsey Map Collection, Stanford Libraries
5 historical maps cover this location, the earliest the 1883 map "Watershed map England, Wales 3." (David Rumsey Map Collection, Stanford Libraries).
Historical maps covering this location
- 1883 · Watershed map England, Wales 3. (David Rumsey Map Collection, Stanford Libraries)
- 1896 · Sheet 7. Ordnance Survey of England and Wales. (David Rumsey Map Collection, Stanford Libraries)
- 1899 · 105 Carnarvon (Hills) (David Rumsey Map Collection, Stanford Libraries)
- 1901 · Sheet 9 and 10. (David Rumsey Map Collection, Stanford Libraries)
- 1919 · Sheet 41. Anglesey. (David Rumsey Map Collection, Stanford Libraries)
Cadw's description
Location
Spanning a dry dock.
History
Dated 1883 by Frederick Jackson, engineer of Nottingham, and built by Oliver & Co of Chesterfield. Built over the entrance to the dry dock of the harbour, which was completed in 1874. A similar bridge was built over the harbour entrance.
Exterior
Principally constructed of rolled steel sections, and comprising 2 sections cantilevered on triple axles, designed to be pulled back manually on short lengths of rail. The deck of each section is laid with wooden boards on a steel frame, which has X-shaped panels below a hand rail and bellied outer struts. Simple arches are at the centre and ends. At the ends are cast iron boxes, for ropes or lifebelts, with name plates. The ramps at either end are replaced.
Reason for designation
Listed for group value with the dock walls and as a rare surviving C19 footbridge in a dockland context.
