Engine House, Boilerhouse, Bunker and remains of chimney to south
Llanllyfni, Gwynedd, Wales
The record
- Designation
- Listed building, Grade II*
- Broad class
- Industrial
- Date of designation
- 10 December 1992
- Locality
- Nantlle
- Community
- Llanllyfni
- Unitary authority
- Gwynedd
- Country
- Wales
- Coordinates
- 53.05417, -4.24347
- Cadw reference
- 22901
Slide toward Today to fade the historical sheet and see the modern map underneath.
David Rumsey Map Collection, Stanford LibrariesDavid Rumsey Map Collection, Stanford LibrariesDavid Rumsey Map Collection, Stanford LibrariesDavid Rumsey Map Collection, Stanford LibrariesLlyfrgell Genedlaethol Cymru – The National Library of Wales
Shown on 5 historical map sheets, the earliest the 1795 "To Sir Watkin Williams-Wynn Bart ... the map of the six counties of North Wales is most humbly inscribed by his obedient humble servant" (Llyfrgell Genedlaethol Cymru – The National Library of Wales).
Cadw's description
Location
On a ridge of bastard rock which divides the main Dorothea Quarry from the South Dorothea Quarry; located by the side of the road access to the quarry.
History
The Dorothea Quarry in the centre of the Nantlle vale was opened in 1829 by William Turner and John Morgan. From 1853 the quarry was owned by the Williams family until its closure in 1970. In 1904 (date on foundation stone) a Cornish beam engine was installed, replacing water power, to provide power for lifting wagons in and out of the open pits and to pump out the workings through a shaft about 140m deep. The engine, manufactured by Holman Bros. of Camborne (Cornwall) remained in regular use until 1952 and occasionally until 1956.
Exterior
Sawn squared slate blocks with gable-ended slate roof 3 storeys over basement. Rectangular plan, aligned roughly north-west to south-east. Small-paned sash windows with slate lintels and cills on each face. Entrance in south-east end wall under brick arch approached by sawn slab steps. Large ground-floor opening in north-west end wall, also with brick arch. Remains of clock high up between top-floor windows on north-east wall. Iron beam of engine supported high up on north-west wall and projecting through vertical timber boarding in gable; pair of doors flanking beam open out on to remains of wooded inspection balconies. At the north-west end the shaft head is surrounded by a wall of sawn slate blocks approximately 2m high and attached to the engine house; the shaft head is spanned by 2 steel joists. Against the south-west wall of the engine house are the remains of the boiler house, now roofless but with the principal timbers surviving; it houses the remains of 2 boilers. To the south is the square base of the remote chimney, constructed of sawn slate blocks, approximately 3m high; the former iron extension has been removed.
Interior
Access to interior not available at time of survey but noted as retaining its early C20 Cornish beam engine.
Reason for designation
Listed Grade II* as the only remaining example of an engine house with a Cornish beam engine remaining in situ within the area of the Gwynedd slate industry.
Scheduled Ancient Monument (No.165).
