5 Waterside

The Department's description

Exterior description and setting

A three-storey-with-basement ruled-and-lined rendered plainly detailed Georgian-style terraced house, two openings wide with a modern glazed shop front to ground floor and dental surgery above. Built c.1850 and located on the western side of Coleraine town, the building forms part of a terrace comprising similar buildings and is abutted to each side by (HB03/16/001B & HB03/16/001D).

Pitched slate roof with blue/grey angled ridge-tiles; brick chimney to right-side having six clay pots; ogee uPVC rainwater goods and square downpipes, mounted on plain timber fascia to boxed eaves. Walling is ruled-and-lined rendered and painted. Square-headed uPVC windows throughout (unless otherwise stated).

Principal elevation faces south and comprises two windows to the upper floors; each having projecting moulded architraves; projecting painted sills which are continuous on first floor. Polished stone cladding to shop front on ground floor having an expansive plain glass three-paned window; recessed modern timber and glazed door to right-side having plain glass transom over; plain glass projecting sidelights; narrow glazing strip to right of shop front; modern vinyl/uPVC signage across length of elevation.

The west elevation is abutted by adjoining terrace (HB03/16/001D).

Rear (north) elevation has a single enlarged rectangular window to left-side of upper floor; enlarged opening to window below with timber fire-escape door inserted; windows to right-side blocked and rendered over. Substantial two-stage flat-roof extension (mid 20th century and c.2005) abuts to ground floor and basement levels, extending north and abutting to the neighbouring building. The left cheek is blank This is a remodelling of a previous extension with former window openings blocked up on the left cheek; north elevation has recent concrete stairs to right with timber sheeted access door to basement on left; modern glazed entrance to shop on ground floor from steps with modern metal spiral stair to left, providing fire-escape route from timber walkway on split level roof of extension.

The east elevation is abutted by adjoining terrace (HB03/16/001B).

Setting
Located in an urban/residential
setting, the main elevation directly fronts one of the main thoroughfares into Coleraine town centre via the nearby ‘Old Bridge’. Situated on the western banks of the River Bann to the west of Coleraine’s central Diamond the building forms part of a terrace comprising similar buildings, which abut on each side, extending westward (HB03/16/001A&B) and eastward (HB03/16/001D-J). A similar terrace is situated on the opposite side of the street, to the south (HB03/16/001K-T). Directly to the rear is a shared yard with modern entrance gates, enclosed on all sides by the substantial returns and extensions of neighbouring buildings. The rear of the building is abutted by a two-storey flat-roofed extension and acts as another main entrance into the ground floor shop via the car park to the north.

Roof Slate
RWG uPVC
Walling Ruled-and-lined rendered
Windows uPVC

Historical information

Constructed as part of a phased terrace c.1846-54, the design of which was overseen by Samuel Angell, the buildings are first shown on the second edition OS map (1849-50). The terrace replaced a previous street, as shown on the first edition OS map (1830), which comprised buildings laid out to a similar pattern, with extensive outbuildings to the rear.

Under the ownership of the Worshipful Company of Clothworkers, this house was first occupied by Peter Martin and valued at £22 in Griffith’s Valuation (1856). This value did not significantly alter. Having a number of occupiers, ownership transferred to Sir Hervey Bruce in 1868 and by 1875 William and George Gilmore were operating a grocer’s shop from the ground floor (General Revisions 1866-84). Census Records (1901 & 1911) show George Gilmore and eight family members were living in the house above and the outbuildings to the rear included a stable, shed and store. The ground floor continued to be utilised as a shop, occupied by a Miss Hughes in 1916, followed by a James White in 1927. Contemporary OS maps (1882-1968) show the building foot-print remained unchanged since construction, except for the removal of the outbuildings to the north coupled with the addition of an extension to the rear, prior to 1904, which has been remodelled and extended in recent years.

This area of Killowen Parish, now known as Waterside, was originally a suburb of Coleraine town and under the ownership of the Worshipful Company of Clothworkers, one of the London Merchant Companies charged with developing and ‘planting’ the county of Londonderry during the early 17th century. The Company chose to lease out these lands, often to absentee landlords, which resulted in a general decline of the estate and a lack of house construction due to the uncertainty of tenures. The Company regained direct control of their proportion in 1840 when the lease had expired and a subsequent era of improvement followed which included substantial expenditure on buildings, infrastructure and education (Mullin; Rowan).

A new bridge of increased height was built c.1844, to replace a previous timber construction c.1735 and stabilising works were carried out to the western embankment of the river (OS Memoirs). During this time the street-level on the Killowen side was raised to correspond with that of the new bridge, which impacted upon the existing buildings. Reflecting the spirit of the times, it was deemed more appropriate to demolish and rebuild the entire area of Waterside, in order to create a more dignified entry into the Company’s estate from the main part of Coleraine to the east (Mullin).

The general layout of Waterside had already been established prior to redevelopment and therefore the terrace did not alter much on plan. However, the design, scale and style of the new buildings adhered to a strict architectural rigour, which had been established by the erection of the neighbouring Clothworkers’ Arms Hotel c.1846 (HB03/16/001A). The hotel marked the first stage of the new development and the demolition of the neighbouring houses commenced in 1847. A new suitable terrace was designed by Samuel Angell, the Company’s surveyor in Ulster, to compliment the eminent building and to line the almost processional approach into the Clothworkers’ Estate from Coleraine town, via the new bridge. Although designs for the individual buildings were largely generated by other architects, each was strictly regulated by Angell and surveyor Stewart Gordon, to conform to the overall scheme. Completed c.1854, the Clothworkers’ Company claimed to have spent approximately £4,00 on the erection of houses in the Waterside area during this period (Mullin).

As Curl (1986) states, the plain, balanced and unembellished style of this terrace represents the conscious decision of the Clothworker’s Company to refrain from the excessive ornamentation, which was embraced by other London Companies during this period of widespread architectural improvement (Curl).

References

1. PRONI OS/6/1/11/1 – First Edition Ordnance Survey map (1830)
2. PRONI OS/6/5/7/2 – Second Edition Ordnance Survey map (1849-50)
3. PRONI OS/9/24/1/8 – Town Plan map (1882)
4. PRONI OS/6/1/11/3 – Third Edition Ordnance Survey map (1904)
5. PRONI OS/6/1/11/4 – Fourth Edition Ordnance Survey map (1921)
6. PRONI OS/10/5/7/7/3– Third Edition Ordnance Survey 25-Inch map (1949)
7. PRONI OS/11/13/13/1 – First Edition Ordnance Survey 25-Inch Irish Grid map (1967-8)
8. PRONI VAL/1/B/57 – Townland Valuations (1830s)
9. PRONI VAL/2/B/5/3F – Griffith’s Valuation (1856)
10. PRONI VAL/12/B/30/9A- General Revisions (1859-65)
11. PRONI VAL/12/B/30/9B- General Revisions (1866-74)
12. PRONI VAL/12/B/30/9C- General Revisions (1875-84)
13. PRONI VAL/12/B/30/9E- General Revisions (1885-92)
14. PRONI VAL/12/B/30/9G- General Revisions (1893-99)
15. PRONI VAL/12/B/30/9M- General Revisions (1900-12)
16. PRONI VAL/12/B/30/9P- General Revisions (1913-31)
17. PRONI VAL/3/B/6/3 – First General Revaluations (1935)
18. Census Records (1901 & 1911)

Secondary Sources

1. Lewis, Samuel ‘A Topographical Dictionary of Ireland’ S. Lewis & Co, London (1837)
2. Day, Angélique and McWilliams, Patrick (eds) ‘Ordnance Survey Memoirs; The Parishes of Co. Londonderry (Vol. 33) XII 1829-30, 1832, 1834-6, Coleraine & Mouth of the Bann’ Institute of Irish Studies, Queen’s University, Belfast (1993)
3. Mullin, Rev. T.H. ‘Coleraine in Modern Times’ Century Services Ltd. Belfast (1977)
4. Rowan, Alistair ‘The Buildings of Ireland: North West Ulster’ Yale University Press, London (1979)
5. Curl, James. S. ‘The Londonderry Plantation 1609-1914’ Phillimore & Co, Chichester (1986)
6. Girvan, W.D. ‘List of Historic Buildings, Groups of Buildings & Areas of Architectural Importance in Coleraine & Portstewart’ Ulster Architectural Heritage Society, Belfast, (1973)
7. www.dia.ie

Criteria for listing: architectural interest

A. Style
B. Proportion
C. Ornamentation
H-. Alterations detracting from building
J. Setting
K. Group value

Criteria for listing: historic interest

X. Local Interest
V. Authorship
R. Age
U. Historic Associations

Evaluation

A three-storey building constituting part of a largely homogeneous, Georgian-style terrace. Constructed c1847-1854 to designs overseen by Samuel Angell and Stewart Gordon. The building is representative of the typical urban form of living accommodation over a shop, while the terrace is characterised by common design principles such as restrained detailing, rendered walling and tall narrow frontages having large regular fenestration patterns over shop fronts. The integrity of this character has been largely retained across the upper floors but incremental changes to the ground floor shops over the decades has resulted in the erosion of some historic fabric. This northern terrace remains important to the visual balance of Waterside as a whole, helping to define the character of one of the main approaches into Coleraine and presenting one of the only coherent street facades within the town. This area of Killowen Parish, now known as Waterside, was originally a suburb of Coleraine town and under the ownership of the Worshipful Company of Clothworkers, one of the London Merchant Companies charged with developing and ‘planting’ the county of Londonderry during the early 17th century. Reflecting the spirit of the times, it was deemed more appropriate to demolish and rebuild the entire area of Waterside, in order to create a more dignified entry into the Company’s estate from the main part of Coleraine to the east. No. 5 is an important element within this overall redevelopment of Waterside and has group value with the other listed buildings in this terrace.

General comments

Listing Criteria R - Age and U - Historic Associations also apply.
Previously recorded as HB03/16/001
